Parts & Specifications: YAMAHA XS 650 | Louis Motorcycle & Leisure

Spare parts and accessories for YAMAHA XS 650

1975 - 1983

Specifications*

Engine size:

654

Cylinders:

hp/kW:

50/37

Vehicle weight (kg):

230

Valve clearance (intake):

KALT 0,05 MM

Valve clearance (exhaust):

K:0,15-'79/0,1-'81

Engine idle speed:

1150-1250 U/MIN

Carburettor air screw:

1,25 AUSDREHUNGEN

Tyre pressure (front):

1,6 (2,0) BAR

Tyre pressure (rear):

2,0 (2,3) BAR

Spark plug 1:

NGK BP8ES

Electrode gap:

0,7 MM

Fork tube diam.:

35 MM TELEGABEL

Front/rear sprockets:

17/33 ZÄHNE

Chain/Final drive:

104 GLIEDER

Specifications*

Engine size:

654

Cylinders:

hp/kW:

50/37

Vehicle weight (kg):

230

Valve clearance (intake):

KALT 0,05 MM

Valve clearance (exhaust):

K:0,15-'79/0,1-'81

Engine idle speed:

1150-1250 U/MIN

Carburettor air screw:

1,25 AUSDREHUNGEN

Tyre pressure (front):

1,6 (2,0) BAR

Tyre pressure (rear):

2,0 (2,3) BAR

Spark plug 1:

NGK BP8ES

Electrode gap:

0,7 MM

Fork tube diam.:

35 MM TELEGABEL

Front/rear sprockets:

17/33 ZÄHNE

Chain/Final drive:

104 GLIEDER

Capacities*

Fork oil per rod:

169 ML SAE 10W-30

Engine oil w/o filter:

2,3 L SAE 20W-40

Engine oil with filter:

2,6 LITER

Brake fluid:

DOT 4

Fuel:

15,0 LITER

Coolant:

LUFTGEKÜHLT

Capacities*

Fork oil per rod:

169 ML SAE 10W-30

Engine oil w/o filter:

2,3 L SAE 20W-40

Engine oil with filter:

2,6 LITER

Brake fluid:

DOT 4

Fuel:

15,0 LITER

Coolant:

LUFTGEKÜHLT

Test reports and information

TOURENFAHRER 2/83

TOURENFAHRER 1/85

MOTORRAD 6/12

Find used value:

DAT GmbH

Test reports and information*

TOURENFAHRER 2/83

TOURENFAHRER 1/85

MOTORRAD 6/12

Find used value:

DAT GmbH
