Save your vehicles here to view the accessories and wearing parts Louis carries for your particular model, as well as key data on settings, capacities and so on. More...
Specifications*:
Engine size:
1043
Cylinders:
4
hp/kW:
138/102, 98/72
Vehicle weight (kg):
222
Seat height (mm):
815
Engine idle speed:
1100 ± 50 U/MIN
Carburettor air screw:
EINSPRITZUNG 38 MM
Tyre pressure (front):
2,5 BAR
Tyre pressure (rear):
2,9 BAR
Spark plug 1:
NGK CR9EIA-9
Electrode gap:
0,9 MM
Fork tube diam.:
41 MM USD-GABEL
Front/rear sprockets:
15/42 ZÄHNE
Capacities*:
Fork oil per rod:
365 ML SAE 10W
Engine oil w/o filter:
SAE 10W-40
Engine oil with filter:
3,8 L MIN. API SG
Brake fluid:
DOT 4
Fuel:
15,5 LITER
Coolant:
2,9 LITER
* Louis has taken great care in compiling the specifications and associated products. They apply to the model of the selected vehicle that is sold in Germany. The specifications of models sold in other countries may differ. Louis does not accept any responsibility for the accuracy of the information provided.
Prior to installation, you should consult your motorcycle's handbook and/or seek information from the manufacturer.
