Specifications*:
Engine size:
1171
Cylinders:
4
hp/kW:
130/96, 98/72
Vehicle weight (kg):
300
Seat height (mm):
790
Valve clearance (intake):
KALT 0,15-0,20 MM
Valve clearance (exhaust):
KALT 0,25-0,30 MM
Engine idle speed:
900 ± 150 U/MIN
Carburettor air screw:
EINSPRITZUNG 38MM
Tyre pressure (front):
2,5 (2,9) BAR
Tyre pressure (rear):
2,5 (2,9) BAR
Spark plug 1:
NGK DCPR7E
Spark plug 2:
NGK DCPR7EIX
Electrode gap:
0,8 MM
Fork tube diam.:
41 MM TELELEVER
Chain/Final drive:
KARDAN
Capacities*:
Fork oil per rod:
510 ML SAE 7,5W
Engine oil w/o filter:
SAE 10W-40
Engine oil with filter:
3,75 L MIN. API SG
Gear oil:
600ML 75W-140 GL-5
Brake fluid:
DOT 4
Final drive oil:
230ML 75W-140 GL-5
Fuel:
20,5 LITER
Coolant:
WASSER+
* Louis has taken great care in compiling the specifications and associated products. They apply to the model of the selected vehicle that is sold in Germany. The specifications of models sold in other countries may differ. Louis does not accept any responsibility for the accuracy of the information provided.
Prior to installation, you should consult your motorcycle's handbook and/or seek information from the manufacturer.
